16M55G4000/5

The 16M55G4000/5 is a top-tier dg engine built for the most demanding heavy-duty, continuous-service power generation applications, delivering high torque, exceptional output, and superior fuel savings across a wide range of operating conditions. Backed by a leading diesel generator engine supplier in India, it meets stringent environmental emission benchmarks. It is ideally configured for manufacturing facilities, large greenhouses, and cogeneration projects, prioritizing rugged reliability, operational flexibility, and an extended life cycle.

ENGINE DATA

Speed (RPM)1500
Bore x Stroke (mm)150 X 185
Displacement (L)87.5
No. of Cylinders16 – Vee
Compression Ratio16.5:1
Total Lube Oil Capacity (L)582
Injection Pump TypeHPCR
Starting System Voltage24V DC
Dimensions (L x B x H) mm5033 x 2996 x 3150
Weight (kg)13600
